HP Z2 Small Form Factor G9 Workstation (6H902UT)

Appearance

• Form Factor
  • HP Z2 Small Form Factor G9 Workstation
• Color
  • Black
• Dimensions
  • 14.6 x 6.7 x 15.2 in
• Weight
  • 15.43 lbs.

System Specifications

• Series
  • Z2 G9
  • Z2 G9
• Operating System
  • Windows 11 Pro (preinstalled with Windows 10 Pro Downgrade)
• Processor
  • Intel Core i5 12500 (up to 4.6 GHz with Intel® Turbo Boost Technology, 18 MB L3 cache, 6 cores, 12 t
• Chipset
  • Intel W680
• Graphics
  • Intel® UHD Graphics 770
• Memory
  • 16 GB DDR4-3200 MHz RAM (1 x16 GB)
  • 4 DIMM
• Internal Storage
  • 512 GB NVMe SSD
• Optical Drive
  • No

Ports and Expansion Slots

• Ports
  • 2 USB 2.0 Ports
  • 8 USB 3 Ports
  • 2 DisplayPorts
  • 1 RJ45 Network Port
  • 1 Headphone Jack
  • 1 Microphone Jack
  • 1 Headphone/Mic Combo Jack
• Expansion Slots
  • 1 PCI Express x16 Slot
  • 1 PCI Express x4 Slot
  • 2 PCI Express x1 Slots
  • 1 PCIe 3 x4 (x16 connector)
    2 PCIe 3 x1 (x1 connector)
    1 PCIe 3 x16 (x16 connector)
    1 M.2 2230 PCIe 3 x1
    2 M.2 2280 PCIe 3 x41 M.2 2230 slot for WLAN and 2 M.2 2280 slots for storage
• External Drive Bays
  • One 3.5" HDD
• Internal Drive Bays
  • One 2.5" One 3.5" Two M.2 NVMe 2280 SSD

Input / Output

• Speakers
  • Speaker
• Audio
  • Conexant CX20632-31Z, 1.5W internal mono speaker
• Keyboard
  • Wired
• Mouse
  • Wired

Network Communications

Power

• Power Supply
  • 310 W internal power supply, up to 90% efficiency, active PFC

What's Included

• In the box
  • Workstation USB Keyboard USB Mouse Power Cable
• Software
  • CyberLink PowerDVD HP Client Security Software HP Manageability Integration Kit Gen2 HP PC Hardware Diagnostics UEFI HP Performance Advisor HP Remote Graphics Software (RGS) 7.1 HP Sure Recover PDF Complete - Corporate Edition
• Warranty
  • 3-year warranty
